1. Product Specifications (mm):

   • Cat Litter Box: 545*545*595
   • Cat Litter Mat: 450*600
   • Garbage Bag: 440*320
   • Aromatic Gel: 100*48
   • Packaging Size: 575*575*665mm

2. Product Weight (g):

   • Net Weight: 13,500
   • Gross Weight: 17,700

3. Packaging Format:

   • Packaged in a cardboard box

4. Combination:

   • Includes cat litter mat for sale

5. Product Highlights:

Integrated Design for Ultimate Cleanliness:

Our one-piece design ensures a hygienic environment by preventing feces from flowing back. The litter box remains stationary with the internal bucket, preventing dirt and soiling for a mess-free experience.

Triple Safety Protection

• Weight sensor: Stops operation when weight changes are detected, with real-time weight monitoring on the app.
• Infrared sensor: Stops operation when a cat approaches the roller entrance (effective within 2-3m).
• Software-controlled motor overcurrent and overload protection.

Detachable Deodorant Aromatic Gel:

Experience continuous freshness with our detachable deodorant aromatic gel that decomposes odors, purifying the air around the litter box for up to 30 days.

Automation & UV Sterilization

• Automatic cleaning and rotation through the app or main unit button.
• Set scheduled cleanings after the cat leaves the box.
• Emphasizes UV sterilization for preventing bacterial growth, especially E. coli. App notifies when the waste compartment is full.

Whisper-Quiet Operation:

Experience peace and quiet with our high-power, high-torque motor and precision-engineered gears, resulting in a noise index as low as 30db.

Heavy-Duty Top for Versatility:

Our litter box's top can support weights exceeding 50kg, allowing you to place items like companions and flower pots. Even after power-off, items can be safely placed on the litter box without affecting the weight sensor's functionality.

Spacious Litter Collection Bin:

The litter bin has a substantial capacity of approximately 6L. Lab tests indicate that it can accommodate one week's worth of waste for two cats and up to 15 days for a single-cat household.

Trash Bags

• 44*32cm bags with a unique drawstring design for easy disposal.

Automate Your Cleanup Routine:

Effortlessly control automatic cleaning, one-button tilting, UV sterilization, and receive timely reminders when the litter bin is full through the Tuya app or easy button controls.

Easy Cleaning Steps for Convenience:

Cleaning is a breeze – simply lift the lid and clean the rolling drum. After cleaning, wipe the internal bucket dry. Please note that the main unit is not washable.

Compatibility with Various Cat Litters

• The filter's long, integrated design ensures strength and compatibility with most cat litters. Recommended: a mix of sand and bentonite; pure tofu cat litter may stick to walls when the amount is low. Note: Cat litter capacity not exceeding 6.5L, with a MAX line reminder. Suggested replacement every two weeks to avoid sticking to walls.

App Operation Instructions

1. Initial setup instructions for connecting to the app.
2. Power-on self-check, indicating correct roller position.
3. Demonstration of bag installation during power-on self-check.
4. During the self-check, the infrared sensor is inactive, but gravity sensor works.
5. In operation, the infrared sensor stops the machine upon detecting movement. One manual button press resumes operation until completion.
6. Counterclockwise rotation for cleaning, clockwise for waste disposal.

Packaging Contents

• 1 Cat litter box
• 1 Cat litter mat
• 3 Rolls of trash bags
• 4 Deodorizing gel packs
• 1 US standard power adapter

Operating Environment

1. Working Voltage/Current: DC12V/2A (requires original adapter).
2. Operating Temperature: 0°C to 40°C.
